MAGMAWELD 6011 3.2mm GP Cellulous Stick Electrodes 5KG
$79.00
Product Introduction
MAGMAWELD 6011 is a general-purpose cellulosic stick electrode with 3.2mm diameter, ideal for root and fill passes in vertical down direction. It offers deep penetration, suitable for shipbuilding, pipelines, and mild steel repair, meeting AWS/ASME SFA-5.1 and EN ISO 2560 standards.
Product Parameters
| Thickness | 3.2mm |
| Length | 350mm |
| Weight | 5kg (181 sticks approx.) |
| Standards | AWS E6011, EN ISO 2560-A E35 2 C 21 |
| Applications | Shipbuilding, pipelines, mild steel repair |
MAGMAWELD 6011 3.2mm Cellulosic Stick Electrodes – 5KG Pack: Your Go-To Solution for Industrial Welding
Why Choose MAGMAWELD 6011 Electrodes?
Designed for professionals seeking reliable performance in challenging welding scenarios, MAGMAWELD 6011 electrodes deliver exceptional penetration and versatility. Perfect for wide gaps and vertical-down applications, these industrial-grade electrodes ensure strong, consistent welds across mild steel, castings, and galvanized sheets¡ªideal for shipbuilding, pipelines, and heavy machinery repair.
Core Specifications
| Description | Details |
|---|---|
| Thickness Diameter | 3.2mm |
| Length | 350mm |
| Weight | 5kg (181 sticks approx.) |
| Flux Type | Cellulosic (no redrying required) |
| Welding Current | AC/DCEN (-) for root passes; AC/DCEP (+) for fill/cap |
| Standards | AWS/ASME SFA-5.1 E6011, EN ISO 2560-A E35 2 C 21 |
| Certifications | CWB, CE |
| Tensile Strength | 530 N/mm2 |
| Yield Strength | 470 N/mm2 |
| Charpy V-Notch (at -20¡ãC) | 50 J |
Key Performance Advantages
- Deep Penetration: Cellulose flux ensures superior gap bridging, ideal for poor fit-up joints.
- Multi-Position Welding: Suitable for PA (flat), PB (horizontal), PC (vertical), PD (overhead), and 3G/4G pipe positions.
- High-Quality Deposit: Low impurities (P/S ¡Ü0.01%) and excellent mechanical properties for durable welds.
- Time-Saving: No redrying needed¡ªready to use straight from storage.
Applications
Trusted in shipbuilding, storage vessels, boilers, pipeline construction, and machinery repair. Perfect for mild steel, steel castings, and galvanized sheets in both assembly and maintenance work.
Quality You Can Rely On
Manufactured by Magmaweld, a market-leading brand, these electrodes meet international standards and carry CWB and CE certifications. Each 5kg pack ensures consistent quality for industrial-grade projects.
FAQ
Q: Can these electrodes be used on AC and DC?
A: Yes¡ªAC or DCEN (-) for root passes; AC or DCEP (+) for fill/cap passes.
Q: Do they require redrying?
A: No, cellulose flux eliminates the need for redrying.
Q: What materials are compatible?
A: Mild steel, steel castings, galvanized sheets, and machinery parts.
Ready to Elevate Your Welding Projects?
For bulk orders or technical inquiries, contact us today. Our expert team will help you secure the best solution for your industrial needs.
