40m 35mm2 2 Gauge Welding Cable Solar Car Battery AU
$660.00
Product Introduction
Australian made 40m welding cable with 35mm2 (2 Gauge) high purity oxygen-free copper conductors. Features double insulated NBR/NBR outer shell rated to 90oC, ensuring softness, flexibility and compliance to AS1995:2003. Ideal for welding applications, equivalent to UNIMIG WC35MM / U51027.
Specifications
| Length | 40m |
| Cross-Section | 35mm2 (2 Gauge AWG/B&S) |
| Max Current | 416 Amp (30% Duty Cycle) |
| Insulation | Double NBR/NBR, 90oC Rated |
| Material | 100% Oxygen Free Copper |
40m Welding Cable – 35mm2 – 2 Gauge – Solar – Car Battery AUSTRALIAN MADE
Upgrade your welding operations with our premium Australian-made welding cable, engineered for superior performance and durability. Whether you’re working on industrial projects, solar installations, or automotive battery connections, this cable delivers reliable power transmission and flexibility to handle demanding tasks.
Key Specifications
| Length | 40m (single continuous length) |
| Cross-Sectional Area | 35mm2 |
| Gauge | 2 AWG/B&S |
| Max Current (30% Duty Cycle) | 416 Amp |
| Conductor Material | 100% Oxygen-Free Copper |
| Insulation | Double Insulated NBR/NBR (V90HT, 90oC Rated) |
| Flexibility | Extra Fine Copper Conductors for Enhanced Flexibility |
| Compliance | AS1995:2003 Standard |
| Origin | Australian Made |
| Equivalent Part | UNIMIG WC35MM / U51027 |
Core Benefits
? Superior Conductivity: High-purity oxygen-free copper ensures minimal power loss and stable current flow, ideal for high-amperage welding applications.
? Extreme Flexibility: Extra fine copper strands and soft NBR insulation allow easy maneuvering in tight spaces, reducing operator fatigue.
? Heat & Chemical Resistance: V90HT-rated insulation withstands temperatures up to 90oC and resists oils, solvents, and abrasion for long-term reliability.
? Australian Quality: Manufactured locally to strict AS1995:2003 standards, guaranteeing consistent performance and safety.
Applications
Perfect for: Welding equipment, solar power systems, car battery connections, industrial machinery, and heavy-duty electrical installations. Its versatility makes it a must-have for professionals in construction, automotive repair, and renewable energy sectors.
Why Choose Our Welding Cable?
Unlike generic cables, our Powerflex cable combines Australian craftsmanship with advanced materials. The double-insulated design offers superior protection compared to single-layer alternatives, while the extra fine conductors ensure maximum flexibility without compromising on durability. It¡¯s the trusted choice for tradespeople who demand reliability in every job.
FAQ
Q: Is this cable suitable for outdoor use?
A: Yes, the NBR insulation provides weather and UV resistance, making it suitable for indoor and outdoor applications.
Q: Can I use this for both AC and DC welding?
A: Absolutely, it¡¯s designed to handle both AC and DC currents efficiently.
Q: Does the cable come with connectors?
A: No, connectors are sold separately to allow customization based on your specific equipment.
Request a Quote Today
Ready to enhance your welding setup with a premium, Australian-made cable? Contact us now for bulk pricing, technical support, or to discuss your specific requirements. Our team is here to help you find the perfect solution for your project.
