10x Type 54 LPG Cutting Nozzle Size 00 1-5mm Cuts
$99.00
Product Introduction
10-piece pack of 3-seat LPG cutting nozzles, Type 54 Size 00, ideal for cutting 1-5mm thickness. Suitable for Quickie Gas machines, using Oxygen and LPG. Complies with AS 4603-1999, made from high-quality materials for industrial/daily use.
Specifications
| Cutting Thickness | 1-5mm |
| Gas Type | Oxygen & LPG |
| Operating Pressure (Fuel) | 20 kPa |
| Operating Pressure (Oxy) | 150 Pa |
| Quantity per Pack | 10 tips |
10x 3 Seat LPG Cutting Nozzle Tip Size 00 – Type 54 Cuts 1mm to 5mm
Product Description
High-performance 3-seat LPG cutting nozzle tips designed for precision cutting in industrial and daily applications. This pack includes 10 Type 54 nozzles (Size 00) engineered to cut 1-5mm thickness with exceptional accuracy. Compatible with Quickie Gas cutting machines, these tips deliver reliable performance for metal fabrication, maintenance, and workshop tasks.
Core Selling Points
| 1. Precision Cutting | Optimized design for 1-5mm thickness with clean, burr-free edges |
| 2. LPG-Oxygen Compatibility | Specifically formulated for LPG and oxygen gas mixtures |
| 3. AS 4603-1999 Compliance | Meets Australian safety and performance standards |
| 4. 3-Seat Design | Enhanced gas flow control for stable flame and consistent cuts |
| 5. High-Quality Materials | Durable construction for long service life in industrial environments |
| 6. Cost-Effective Pack | 10 tips per pack for continuous workflow and value |
| 7. Brand Equivalents | Compatible with CIG #306104 and BOC PNM 8 systems |
| 8. Efficient Gas Consumption | Optimized fuel (5 L/min) and oxygen (22 L/min) usage |
| 9. Easy Installation | Direct fit for Quickie Gas cutting machines |
| 10. Versatile Application | Suitable for both industrial production and daily maintenance tasks |
Technical Specifications
- Cutting Thickness: 1-5mm
- Fuel Gas: LPG
- Oxygen Pressure: 150 kPa
- Fuel Pressure: 20 kPa
- Gas Consumption (Fuel): ¡Ü5 L/min
- Gas Consumption (Oxygen): ¡Ü22 L/min
- Design: 3-seat
- Quantity: 10 tips/pack
- SKU: 400099
- Compliance: AS 4603-1999
Applications
Ideal for metalworkers, fabricators, and maintenance professionals working with mild steel, carbon steel, and low-alloy steel. Perfect for automotive repair, sheet metal fabrication, HVAC installations, and general industrial cutting tasks requiring precision and efficiency.
Quality Assurance
Manufactured from premium raw materials with strict quality control processes. Each nozzle undergoes pressure testing and dimensional inspection to ensure consistent performance. Backed by our factory’s commitment to industrial-grade reliability.
FAQ
Q: What machines are compatible with these nozzles?
A: Designed for Quickie Gas cutting machines and compatible with systems using CIG 306104 or BOC PNM 8 nozzles.
Q: Can these tips be used with acetylene?
A: No, these are specifically engineered for LPG and oxygen mixtures.
Q: What’s the maximum operating pressure?
A: Oxygen: 150 kPa; Fuel: 20 kPa (always follow machine manufacturer guidelines).
Request a Quote
As a leading Chinese manufacturer, we offer competitive pricing for bulk orders. Contact us today with your requirements for personalized pricing and technical support.
Packaging & Transportation
Weldsuper Nozzles
