Lefon R6 Orbital Pipe Saw Cutter Bevelling Machine
$4,999.00
Product Introduction
LEFON R6 Orbital Pipe Saw is a cost-effective, reliable solution for square cutting and bevelling metal pipes (3″-6″ diameter, 2.0-10mm thickness). It delivers precise, clean cuts without thermal distortion, ideal for orbital welding prep. Features fast clamping, easy setup, and simultaneous cutting/beveling with speed regulation for various wall thicknesses. Manufactured to CE and ISO standards.
Specifications
| Model | R6 |
| Cutting Range | 3″-6″ (85mm-182mm) |
| Power Output | 1600W |
| Blade Speed | 150-250rpm |
| Weight | 90kg |
Lefon R6 Pipe Saw / Cutter – Orbital Bevelling Cutting Machine
Effortlessly achieve precise, square cuts and bevels on metal pipes with the Lefon R6 Orbital Pipe Saw¡ªyour cost-effective solution for professional-grade pipe cutting. Engineered for reliability and efficiency, this machine eliminates post-cut preparation, making it ideal for orbital welding applications. Whether you¡¯re working with stainless steel, aluminum, or plastic pipes, the R6 delivers cold cuts to prevent thermal distortion, ensuring clean results in seconds.
Especificaciones básicas
| R6 (GF^ equivalent) | |
| Pipe Size Range | 3″-6″ (85mm-182mm) |
| Wall Thickness | 2.0mm-10mm |
| Blade Speed | 150-250rpm |
| Power Output | 1600W |
| 100-220V / 50-60Hz | |
| Weight | 90kg |
| CE, ISO | |
| Cutting Time | Single rotation (seconds) |
| Clamping System | Fast, deformation-free |
Key Features & Benefits
- Simultaneous Cutting & Bevelling: Mount a beveling blade to complete cuts and bevels in one operation, saving time.
- Cold Cut Technology: Prevents thermal distortion for precise, clean edges¡ªno post-processing needed.
- Adjustable Speed: Regulate cutting speed to match pipe wall thickness for optimal results.
- Easy Setup: User-friendly design works across pipe diameters with minimal configuration.
- Durable Blades: European-made HSS blades (e.g., TIALN Coated) deliver up to 150 cuts on 2″ schedule 40 stainless steel.
Aplicaciones
Perfect for stainless steel, low/unalloyed steel, cast materials, non-ferrous metals (copper, aluminum), and plastic pipes. Ideal for industries like construction, oil & gas, and manufacturing.
What¡¯s Included
- 1x Base plate
- 1x Cutting machine
- 3x Standard blades
- 1x Ring spanner
- 2x Hexagon socket head wrenches
- 1x Lefon saw blade lubricant
- 1x Operations manual
- 1x Spare parts list
Aseguramiento de Calidad
Manufactured to CE and ISO standards, ensuring safety and performance. Use with XDP 2000 cutting fluid (part 81210) for extended blade life.
Preguntas Frecuentes
Q: Does the machine include a stand?
A: No, a stand is not included.
Q: What blade should I use for beveling?
A: Use the 30DEGCB bevel blade (68mm x 2.0mm, 72 teeth).
Q: Is lubrication required?
A: Yes, always use Lefon lubricant or XDP 2000 cutting fluid for optimal performance.
Ready to enhance your pipe cutting efficiency? Contact us today for a quote or technical support.
